model no. 054-2516-4 | contact us 1-800-689-9928
4
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
Charger input voltage 100 - 240 V 50/60 Hz AC
Rated input current 0.2 A
Charger output voltage 8 V DC
Output current 0.25 A 2 W MAX
Battery 4 V max* (1.3 Ah) lithium-ion
No-load speed 180 RPM
Max torque 2.6 ft-lb (3.5 Nm)
Hex chuck 1/4” (6.4 mm)
AC charging adaptor 3–5 hours
Machine weight 13 oz (0.38 kg)
* Maximum battery voltage without workload; with workload nominal voltage is 3.6V.
