ROUTER TABLE - 054-6938-6
19
To adjust the out-feed fence for
joining (fig 14)
For joining operations, the out-feed fence can be
adjusted up to 9/16" (14.3 mm) in front of the in-
feed fence to support the workpiece after it passes
across the router bit.
1. Turn off the safety switch on the table.
2. Loosen the two clamping knobs on the out-
feed fence.
3. Move the out-feed fence in front of the in-feed fence to a distance equal to the width of material to
be removed from the workpiece. Tighten the clamping knobs.
4. Move and clamp the entire extended fence so that the out-feed fence is aligned with the cutting
edge of the bit.
Adjusting the mitre
gauge (fig 15)
1. Loosen the mitre gauge knob.
2. Rotate the mitre gauge to the desired angle.
3. Tighten the mitre gauge knob.
OPERATING INSTRUCTIONS
fig 14
fig 15
