ROUTER TABLE - 054-6938-6
16
Mounting the table to a work
surface (fig 7)
1. Place the router table upright on a sturdy
surface, such as a work stand, workbench, or
countertop.
2. While holding the router table in place, mark
the location of the two mounting holes
(11/32" [8.7 mm] diam.) in each of the legs on
the work surface.
3. Remove the router table.
4. Drill a hole at each of the marked locations.
5. Place the router table on the work surface, and align the holes in the table legs with the holes in
the work surface.
6. Secure the router table to the work surface using four screws (not included).
7. Tighten the screws securely.
Using the switch
The switch has a safety key to help avoid accidentally switching the router ON and unauthorized and
possibly hazardous use by others.
The safety key must be completely inserted into the switch before the switch can be turned ON.
OPERATING INSTRUCTIONS
fig 7
