ROUTER TABLE - 054-6938-6
15
Attaching the fence to the
table (fig 5)
WARNING!
Always unplug the router before
attaching or removing the fence.
The fence is shipped completely
assembled.
1. Place the fence assembly on the table, with
the four wing nuts facing toward the operator.
2. Align the two holes on the bottom of the fence
assembly with the two channels on the router
table.
3. Secure the fence to the table using two
clamping knobs (5), two plain washers (11), and
two short round-head square-neck bolts (6).
Attaching the mitre
gauge (fig 6)
1. The mitre gauge is shipped completely
assembled.
2. Attach the mitre gauge to the table by placing
the mitre-gauge bar in the slot on the table.
OPERATING INSTRUCTIONS
fig 5
fig 6
