model no. 054-6988-6 | contact us 1-800-689-9928
10
No. Description No. Description
1 Trigger switch 9 Depth-of-cut scale
2 Lock-on button 10 Dust-extraction adaptor
3 Speed adjuster 11 Chip shield
4 Plunge-lock lever 12 Locking screw
5 Spindle lock 13 Lock bolt
6 Collet nut 14 Base plate
7 Depth-stop turret 15 Bushing adaptor
8 Depth-stop bar
KEY PARTS DIAGRAM
