PACKAGE CONTENTS:
Router, collet wrench, chip guard, straight-edge guide, collet/nut, vacuum adaptor (with two screws),
bushing adaptor (with two nuts), 5-piece router bit set, instruction manual.
5-Piece Router Bit Set:
1/4" (6 mm) diameter straight cutting bit, 1/4" (6 mm) radius cove bit, 1/4" (6 mm) radius roundover
bit, 3/8" (10 mm) radius bead bit, 1/8" (3 mm) radius roman ogee bit.
KEY PARTS DIAGRAM
9
12
1
2
5
8
13
6
4
10
3
7 11 14 15
KEY PARTS DIAGRAM
WARNING!
• Remove the router from the package and examine it carefully. Do not discard the carton or any router
material until all parts have been examined.
