model no. 054-6988-6 | contact us 1-800-689-9928
4
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
Rated voltage 120 V~, 60 Hz
Rated power input 10A
Horsepower 1 3/4 HP
No-load speed 0–28,000 RPM
Collet capacity 1/4" (6.4 mm)
Plunge stroke 2 1/8" (55 mm)
Base dimension 6 1/2" (16.5 cm)
Micro-fine depth Adjusts to 1/256" (0.099 mm)
Depth stop 4-position turret stop
Weight 7 lb 11 oz (3.5 kg)
Noise level 95 dB(A)
Vibration a
hi
=1.58 m/s
2
, K=1.5
Sub-base opening (diameter for cutting bit use) 1 1/2" (3.8 cm)
