KEY PARTS DIAGRAM
WARNING!
• Remove the cordless drill/driver from the package, and examine it carefully. Do not discard the carton or
any packaging material until all parts have been examined.
• If any part of the cordless drill/driver is missing or damaged, do not attach the battery pack to the tool
or use the tool until the part has been repaired or replaced. Failure to heed this warning could result in
serious injury.
• Do not allow familiarity with the cordless drill/driver to cause a lack of alertness. A fraction of a second of
carelessness is enough to cause severe injury.
FPO
PACKAGE CONTENTS:
Cordless drill/driver, 2 screwdriver bits, 1 belt clip, 1 bit holder, and instruction manual
KEY PARTS DIAGRAM
No. Description No. Description
1 Two-speed gearbox switch 5 LED worklight
2 Torque-adjustment ring 6 Magnet
3 Keyless chuck 7 Direction-of-rotation selector
4 Trigger switch
Before attempting to use this tool, become familiar with all of its operating features and safety
requirements. For optimum performance and safety, read the following operating instructions carefully
before using.
1
2
3
4
5
6
7
