EXTENSION CORD SAFETY
Make sure any extension cord used with this tool is in good condition. When using an
extension cord, be sure to use one of heavy enough gauge to carry the current the tool will
draw. An undersized cord will cause a drop in line voltage, resulting in loss of power and
overheating.
The table below shows the correct size to use according to cord length and nameplate
ampere rating. If in doubt, use the next heavier gauge. The smaller the gauge number, the
heavier the cord.
Be sure your extension cord is properly wired and in good condition. Always replace a
damaged extension cord or have it repaired by a qualied electrician before using it. Protect
your extension cord from sharp objects, excessive heat and damp or wet areas.
Use a separate electrical circuit for your power tools. This circuit must not be less than 14
gauge wire and should be protected with either a 15A time-delayed fuse or circuit breaker.
Before connecting the power tool to the power source, make sure the switch is in the Off
position and the power source is the same as indicated on the nameplate. Running at lower
voltage will damage the motor.
SAVE THESE INSTRUCTIONS FOR REFERENCE
MINIMUM GAUGE (AWG) EXTENSION CORDS (120V USE ONLY)
Amperage rating Total length
More
than
Not more than 25’
(7.5 m)
50’
(15 m)
100’
(30 m)
150’
(45 m)
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not applicable
V Volts
A Amperes
Hz Hertz
W Watts
kW Kilowatts
Microfarads
L Litres
Kg Kilograms
H Hours
2
Newtons per square centimetre
Pa Pascals
OPM Oscillations per minute
Min Minutes
S Seconds
or AC
Alternating current
Three-phase current
Three-phase alternating current
with neutral
Read all safety instructions
Direct current
No load speed
Alternating or direct current
Class II construction
Splash-proof construction
Watertight construction
Protective grounding at grounding
terminal, Class I tools
Revolutions or reciprocations per
minute
Diameter
0
Off position
Directional arrow
Warning symbol
Wear safety glasses
Wear hearing protection
Wear dust mask
WARNING! Some of these symbols may appear on the chop saw. Study these symbols and learn
of this tool.
13
To Next Page
