12
AIR-POWERED CLIPPED-HEAD FRAMING NAILER 058-8434-4
Air system
•
A
lways use clean, dry, regulated compressed air at 4 to 7 bar (60 to 100 PSI).
• Do not exceed the maximum and minimum pressures. Operating the tool at the wrong
pressure will cause excessive noise, fast wear or misfiring.
• It is recommended that a filter-regulator-lubricator be used and be located as close to the tool
as possible.
• If a filter-regulator-lubricator is not installed, place up to 6 drops of compressor oil into the air
inlet plug before each use.
• If a filter-regulator-lubricator is installed, keep the air filter clean. A dirty filter will reduce the
air pressure to the tool, which will cause a reduction in power, efficiency, and general
performance.
• For optimal performance, install a quick connector to the tool and a quick coupler on the
hose, if applicable.
• Verify that all of the connections in the air supply system are sealed in order to prevent air
from leaking.
N
ote: Please note that the filter-regulator-lubricator and air hose are sold separately.
W
ood density Nail size Compressor air pressure
!0.6 g/cm
3
2.5" (63 mm) 100 psi
t2.5" (63 mm) 110 psi
d0.6 g/cm
3
2.5" (63 mm) 70 psi
t2.5" (63 mm) 110 psi
WARNING!
Potential hazard that could result in serious injury or loss of life.
• Keep hands and other parts of the body away from the work areas when
connecting the air supply. Failure to comply could lead to serious injury or
loss of life.
