PARTS LIST

AIR-POWERED SIPHON-FEED SPRAY GUN 058-9336-2

No. Description Qty. No. Description Qty.

1 Filter 1 27 Trigger pin II 1

2 Paint straw 1 28 Trigger 1

3 Canister 1 29 Snap retainer 3

4 Pin 2 30 Trigger washer 1

5 Pin sleeve 2 31 O-ring 6 X 2 1

6 Washer 1 32 Pattern adjusting bolt 1

7 Handle 1 33 Brass washer 1

8 Anti-leaking washer 1 34 Pattern adjusting bolt seat 1

9 Hanger 1 35 Pattern adjusting nut 1

10 Paint inlet plug 1 36 Bolt M4 X 7 1

11 Nut 1 37 Paint adjusting bolt 1

12 Paint inlet seat 1 38 Paint adjusting nut 1

13 Air cap retainer 1 39 Needle spring 1

14 Round nut 1 40 Needle 1

15 Air cap washer 1 41 Fluid adjusting knob 1

16 Air cap 1 42 Trigger spring 1

17 Nozzle 1 43 Valve stopper 1

18 Nozzle housing 1 44 O-ring 4.5 X 1.8 1

19 Washer 1 45 Valve stem 1

20 Washer 1 46 Hex bolt 1

21 Position bolt 1 47 Compressed spring 1

22 Needle sealing washer 1 48 Brass washer 1

23 Washer 1 49 O-ring 2.5 X 1.2 1

24 Compressed spring 1 50 O-ring 9 X 1.2 1

25 Washer 1 51 Valve seat 1

26 Trigger pin I 1 52 Bolt 1
