model no. 062-3420-4 | contact us 1-800-689-9928
6
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
Liquid temperature range 32 to 77°F (0 to 25°C)
Impeller Plastic
Discharge size 1 1/4” (3.2 cm) Female NPT
Seal Mechanical seal
Cord length 8’ (2.4 m)
Upper bearing Sleeve bearing
Lower bearing Sleeve bearing
Single phase Permanent split capacitor (PSC)
Motor protection Auto-reset thermal overload protection in motor
Construction material Steel for motor house; plastic for volute and impeller
Motor Squirrel cage induction, class B insulation
Maximum flow 1300 U.S. GPH (4921 L/hr)
Maximum head height 15’ (4.6 m)
MOTOR AND ELECTRICAL
SKU number 062-3420-4
HP 1/3
Volt/ph 115/2
Hz 60
RPM 1725
Full load amps 4
Cord size 18 AWG
Cord type SJTW
