model no. 062-3579-8 | contact us 1-800-689-9928
14
OPERATING INSTRUCTIONS
• The shaft seal depends on water for lubrication. Do not operate the pump unless it is
submerged in water as the seal may be damaged if allowed to run dry.
• The motor is equipped with an automatic reset thermal protector. If temperature in the
motor should rise unduly, the switch will cut off all power before damage can be done
to the motor. When the motor has cooled sufficiently, the switch will reset automatically
and restart the motor. If the protector trips repeatedly, the pump should be removed and
checked. Low voltage, long extension cords, clogged impeller, very low head or lift, a
plugged or frozen discharge pipe, etc., could cause the protector to trip.
• The pump will not remove all water.
• Do not change the preset tether length.
OPERATION
DANGER!
• Risk of electric shock. Can shock, burn or kill. Do not handle a pump or pump motor
with wet hands or when standing on a wet or damp surface or in water.
• Risk of electric shock. Can shock, burn or kill. Before attempting to check why the
unit has stopped operating, disconnect power from the unit.
4 ± 1/2" (10.1 ± 1.3 cm)
