15
MAINTENANCE
TO CLEAN A PUMP CLOGGED WITH DEBRIS:
• Unplug the pump from electrical power.
• Unscrew the stainless screws (5), and remove the volute (4) and gasket (3).
• Use a flathead screwdriver to hold the shaft (1), then turn the impeller (2) counter-
clockwise to release the impeller (2).
• Remove debris from around the shaft (1) and on/under the impeller (2).
• Reassemble the pump.
CARE AND CLEANING
DO DO NOT
When the power is disconnected,inspect
the pump suction screen and remove all
debris, then plug the pump back into the
grounded (GFCI) outlet.
Do not disassemble the motor housing.
This motor has NO repairable internal
parts.
Do not lift up the pump by the power cord.
1
2
3
5
4
CAUTION!
• Always use the handle to lift the pump. Never use the power cord to lift the pump.
To avoid skin burns, unplug the pump and allow time for it to cool after periods
of extended use.
