model no. 062-3593-2 | contact us 1-800-689-9928
6
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
Temperature 32 to 77ºF (0 to 25ºC)
Impeller Plastic
Solids handling 0” (0 mm) spherical
Discharge /suction size 1” (2.5 cm) national pipe thread (NPT)
Seal Mechanical seal
Upper bearing Ball bearing
Lower bearing Ball bearing
Single phase Permanent split capacitor (PSC)
Motor protection Auto-reset thermal overload protection in motor
Construction material Aluminum alloy for motor house: plastic for diffuser and
impeller; stainless steel for pump body
Motor NEMA L, torque curve, squirrel cage induction,
class B insulation
MOTOR AND ELECTRICAL
SKU number 062-3593-2
HP 3/4
Volt 115
Hz 60
RPM 3450
Full load amps 8
NOTE:
The suction pipe size should not be less than 1” (2.5 cm). The suction size of
this pump is 1” (2.5 cm) national pipe thread (NPT).
