Gauges & Video Screens • 2014 MasterCraft Owners Manual Page 3-45
G A U G E S & V I D E O S C R E E N S
MAIN MENU OPTIONS
Menu Options
The Menu is displayed by pressing and
holding [MENU]. The following features
are available:
GPS UTILITIES—Contains options to
set up track and position, chart and time,
and waypoint manager. Also displays satel-
lite status.
USER SETTINGS—Allows you to
customize the display options for ambi-
ent light and brightness, set U.S. or metric
units, specify the Home screen and screen
set-up status.
ENGINE DIAGNOSTICS—Displays
a list of engine fault codes and descrip-
tions; on some engines, corrective action
will be shown.
UTILITIES—Allows conguration of
the unit including wire conguration, plug
address, fault conversion, CAN data, and
fault codes. Also displays software version
information a the top of the page.
• System
• Ballast
• Auto Launch/Exit Setpoint Speed
GPS Utilities
The GPS Utilities includes the follow-
ing:
• Waypoint Manager
• Track Manager
• Chart and Time Set-up
• Depth and Position Settings
• GPS Status
Waypoint Manager
Waypoints are a way to mark specic
locations by latitude and longitude. After
the waypoints are established, the Way-
point Manager allows you to associate an
icon with them for identication. Use the
[LEFT] and [RIGHT] arrows to navigate
the screen. Delete a single waypoint by us-
ing the [DELETE] key, or all of them at
once with [DELETE ALL] (a delete alert
is displayed). Pressing the [GO TO WPT]
key displays the GPS screen containing the
currently highlighted waypoint.
WAYPOINT LIST—Displays a list of
the waypoints that have been set. Use the
[UP] and [DOWN] keys to highlight the
desired waypoint.
WAYPOINT ICON—Allows you to
assign one of four different icons to any of
the waypoints listed.
LAT/LON—Displays latitude and lon-
gitude values for the currently highlighted
waypoint on the list.
