Gauges & Video Screens • 2014 MasterCraft Owners Manual Page 3-33
G A U G E S & V I D E O S C R E E N S
XStar
Video Screen
Operations
Product Information for the XStar
Video Touch and Static (Non-Touch)
Screens
The XStar video screens consist of one
(1) 4.5” video touch screen, one (1) 4.5”
static, non-touch screen, and one (1) 7”
touch screen. A unique feature is that the
4.5” video touch screen and the 7” touch
screen are linked. Some changes made
on either are displayed on both. The 4.5”
static, non-touch screen is independent of
the other two screens and displays engine
and transmission parameters and service
codes. These are multi-functional tools that
provide GPS tracking, multi-media display,
cruise control, rider proles, and enables
equipment operators to view a wide range
of engine, ballast, transmission parameters
and service codes.
Care and Maintenance
Only basic cleaning should be required
to maintain the screens at their best. A soft
