MasterCraft Trailers • 2014 MasterCraft Owners Manual Page 7-37
M A S T E R C R A F T T R A I L E R S
Possible cause: Pinchedor kinked brake
lines.
Remedy: Check the brake lines and replace
as necessary.
If uid does NOT move in Step 5 above,
it means the brake system is remaining
pressurized and there is an actuator issue.
Troubleshoot the actuator.
Possible cause: Pulled breakaway cable
andthepushrodhasnotbeenreset.
Remedy: Reset the breakaway cable and
install the clip.
Other potential issues with the actuator
include:
• the uid return hole in the master cylin-
der is clogged or is not correctly posi-
tioned;
• corrosion in the master cylinder is freez-
ing the piston or not allowing it to fully
retract, which is usually caused by a
trailer being stored with the actuator
compressed;
• or some other malfunction or damage
that is keeping the master cylinder from
retracting.
These are more complex issues and
should be addressed by an authorized Mas-
terCraft dealer.
