18
20V max* LITHIUM-ION CORDLESS DRILL/DRIVER - 054-3118-6
MAINTENANCE
Chuck removal
(g 13)
The chuck can be removed and replaced with a new
one.
1. Remove the battery.
2. Lock the trigger switch by placing the direction-
of-rotation selector in the centre position.
3. Open the chuck jaws. Using a screwdriver,
remove the chuck screw by turning it clockwise.
4. Insert a 5/16-in. or larger hex key into the chuck
of the drill/driver and tighten the chuck jaws
securely.
5. Tap the hex key sharply with a mallet in a counter-clock wise direction. This will loosen the chuck for
easy removal.
6. Attach a new chuck to the spindle and tighten the chuck screw.
fig 13
Chuck jaws
Mallet
Hex wrench
