INSTALLING THE AUXILIARY SIDE
HANDLE
Install the auxiliary handle (1) for two-
handed operation of the drill (Fig. 7). This
is particularly important for drilling large
holes.
NOTE: The auxiliary handle can be
installed on either the left or right side of
the drill housing.
1. Insert the threaded mounting screw
(2) and into the threaded hole in the
drill housing (3).
2. Turn the auxiliary handle clockwise to
tighten it into the drill housing.
NOTE: Tighten the handle by hand only.
Do NOT over tighten the handle or you will
damage the handle or the housing.
BIT STORAGE IN AUXILIARY HANDLE
Screwdriver bits and drill bits can be stored
in the auxiliary handle.
1. To store bits in the auxiliary handle
(1), remove the end cap (2) by turning
it counter-clockwise (Fig. 8).
2. Insert the bits to be stored in the
handle.
3. Insert the end cap into the handle and
tighten it into place by turning it
clockwise.
