SPIRIT LEVEL
The drill is equipped with a dual reading
horizontal/vertical level to assist in keeping
the drill “level” while drilling horizontal and
vertical holes.
The horizontal level (1) is located in the top
of the drill housing (Fig. 11). The vertical
level (2) is located on the rear of the drill
housing.
To maintain a horizontal drilling position,
hold the drill so the horizontal level bubble
(3) is centred in the level indicator circle (4)
(Fig. 12). To maintain a vertical drilling
position, hold the drill so the vertical level
bubble (5) is centred in the level indicator
circle (6) (Fig. 13).
VARIABLE-SPEED TRIGGER SWITCH
This drill is equipped with a variable-speed
ON/OFF trigger switch.
1. To start drill, gently squeeze the
trigger switch (1) (Fig. 14).
NOTE: The drill will turn at its slowest
speed when the trigger switch is
depressed slightly. The drill will turn at its
fastest speed when the trigger switch is
fully depressed.
2. To stop the drill, release the trigger
switch.
NOTE: Drilling at a slow speed for an
extended period of time may cause the drill
motor or the battery pack to overheat. If
either the drill or the battery get hot, stop
drilling and allow them to cool for at least
15 minutes.
