MasterCraft 55-4504-8

IX. Parts List
16
No. Description Qty No. Description Qty
1 Screw M4 x 8 9
2 Flat washer 4 9
3 Cover 1
4 Nut 1
5 Pulley 1
6 Screw M5 x 10 1
7 Bearing 6004-2Z 2
8 Power cable 1
9 Retainer 42 2
10 Headstock 1
11 Spindle 1
12 Face plate 1
13 Spur centre 1
14 Hex bolt M4 2
15 Compression spring 2
16 Handle 2
17 Jointer 1
18 Screw M4 x 14 2
19 Tool rest 1
20 Tool rest support 1
21 Eccentricity shaft (A) 1
22 Retainer B 1
23 Bolt 2
24 Handle 2
25 Compression spring 2
26 Screw M4 1
27 Shaft sleeve 1
28 Threaded rod (A) 1
29 Compression spring 2
30 Side block 2
31 Nut M8 2
32 Cap centre 1
33 Bearing 608 1
34 Cap centre rod 1
35 Tailstock 1
36 Screw M6x10 1
37 Screw M6x10 2
37A Cup assembly (includes parts 32, 33, and 34) 1
38 Tailstock spindle 1
39 Nut M6 1
40 Wheel 1
41 Handle 1
42 Screw 1
43 Handle cap 1
44 Eccentricity shaft (B) 1
45 Threaded sleeve 1
46 Threaded rod B 1
47 Plate 1
48 Hex bolt M6 x 16 2
49 Spring washer 6 2
50 Flat washer 6 2
51 Motor 1
52 Fix plate 1
53 Flat washer 5 4
54 Spring washer 5 4
55 Screw M5 x 12 4
56 Pulley 1
57 Hex bolt M8 x 30 2
58 Spring washer 8 3
59 Hex bolt M8 x 40 1
60 Flat washer 8 3
61 Tool bed 1
62 Clip 1
63 Belt 1
64 Switch box 1
65 Printed circuit board 1
66 Rotation label 1
67 Flat washer 7 1
68 Nut M7 1
69 Adjustable knob 1
70 Switch fix plate 1
71 Overload label 1
72 Tapping screw ST3.5 x 12 2
73 Overload protector 1
74 Switch 1
75 Push-out rod 1
76 Wrench 1
77 Wrench 1
Owner's Manual (not shown) 1
MASTERCRAFT
®
12" Mini Wood Lathe 55-4504-8
