VI. Assembly and Adjustment Instructions
Unpacking (Fig. 1)
CAUTION: THE MINI LATHE IS HEAVY, AND MUST BE LIFTED WITH THE HELP OF
ANOTHER PERSON.
1. Carefully remove the mini lathe and all loose parts from the box.
2. Lay out all of the parts and check them against the parts listed below. Examine all
parts carefully.
For your safety, the lathe must be completely assembled before it is plugged it into the
power supply.
WARNING: IF THERE ARE ANY MISSING OR DAMAGED PARTS, DO NOT PLUG THE
LATHE IN UNTIL ALL MISSING OR DAMAGED PARTS ARE REPLACED.
9
A Mini wood lathe
B Headstock spur centre
C Tailstock cup centre
D Push-out rod
E Flat wrench
F Tool rest
G Faceplate, 5 3/4" (14.5 cm) diameter
H 5/32" (4 mm) hex key
Hardware for mounting the lathe: 3 hex bolts
and washers (not shown)
Fig. 1
A
G
F
H
E
B
C
D
