SECTION PAGE
I. Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
II. General Safety Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
III. Specific Safety Rules for the Mini Wood Lathe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
IV. Electrical Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
V. Diagram and Location of Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
VI. Assembly and Adjustment Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
VII. Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
VIII. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
IX. Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
X. Exploded View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
XI. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
I. Technical Data
Table of Contents
MINI WOOD LATHE
MODEL NUMBER: 55-4504-8
MOTOR: 120 V AC, 60 Hz, 3 A
SPEEDS: 500–3500 RPM
SWITCH: Removable key type
DISTANCE BETWEEN CENTRES: 12" (30 cm)
SWING OVER BED: 8" (20 cm)
DRIVE SPINDLE: 1" (25 mm), 8 TPI thread
DRIVE SPINDLE THROUGH HOLE: 3/8" (10 mm)
TAILSTOCK SPINDLE THROUGH HOLE: 3/8" (10 mm)
TAILSTOCK SPINDLE TRAVEL: 1 1/2" (4 cm)
HEADSTOCK SPUR: Spur centre, Morse #1 taper
TAILSTOCK CENTRE: Ball bearing cap centres, Morse #1 taper
POWER CORD: 8' (2.4 m)
OVERALL SIZE: 30 5/8 x 4 13/16 x 13 1/2"
(77.8 x 12.2 x 33.4 cm)
NET WEIGHT: 43 lb (19.5 kg)
CSA: 184892
2
