MasterCraft MCPAC12KHM User Manual

10
2
Window Slider A
Window Slider B
(if required)
Insert the window slider
assembly into the window
opening.
3
Foam seal C
(Non-adhesive type)
Cut the non-adhesive foam
seal C strip to match the
width of the window. Insert
the seal between the glass
and the window frame to
prevent air and insects from
getting into the room.
4
2 Screws
Security Bracket
If desired, install the
security bracket with
2 screws as shown.
5
Insert the window slider
adaptor into the hole of
the window slider.

MasterCraft MCPAC12KHM Specifications

General

Brand	MasterCraft
Model	MCPAC12KHM
Category	Air Conditioner
Language	English
