MasterCraft MCPAC12KHM User Manual

11
Type 2: Sliding Window Installation
1
Foam seal B
(Adhesive type-shorter)
Foam seal A
(Adhesive type)
Cut the adhesive foam seal
A and B strips to the proper
lengths, and attach them to
the window sash and frame
as shown.
2
Window Slider A
Window Slider B
(if required)
Insert the window slider
assembly into the window
opening.
3
Foam seal C
(Non-adhesive type)
Cut the non-adhesive foam
seal C strip to match the
window height. Insert the
foam seal between the
glass and the window frame
to prevent air and insects
from getting into the room.
4
2 Screws
Security
Bracket
If desired, install the
security bracket with
2 screws as shown.
