MasterCraft X23 2017 - Fuel Management Software and Settings; Using Fuel Management Software

2017 OWNERS MANUAL / 102
This will display the fuel level entry page. The operator can input the
amount of fuel added, or tap the FULL button to indicate that the
tank has been filled completely. Fuel levels will be displayed next to
“Amount” at the top of the screen.
Press SAVE to bring up the confirmation screen below, or press
back to exit to the menu screen if you did not mean to input fuel
levels. Press BACK to exit to the menu screen. From the confirma-
tion screen, the operator can use the hot keys to access any of the
other screens.
Should an operator input the wrong amount of fuel, there are sever-
al fail-safes in place. To immediately correct an input error, push the
Menu hot-key, select User Settings and tap Fuel Settings. This will
Fuel Management Sofware and Settings
The fuel management software in MasterCraft boats directly
connects the boat operator to the management of their fuel. This
system collects precision information on fuel flow levels from the
engine controller. It then accurately calculates and displays the
amount of fuel remaining based on engine activity and the usable
size of the fuel tank.
As a safeguard, there is a back-up low fuel sensor that signals any
discrepancies between the computer and the amount of fuel in the
tank.
Using Fuel Management Sofware
Upon keying the boat on, the touchscreen display will ask the opera-
tor if they have added fuel to the boat.
If the answer is no, tap CANCEL on the screen to close the fuel
management system. If the answer is yes, tap YES on the screen.
open the fuel level entry page. Use the keypad and the +/- button to
adjust to the correct amount of fuel. Use a positive value if more fuel
needs to be entered, or use a negative value if too much fuel was
entered.
When the fuel management system senses that fuel is getting low
it will display a low fuel warning on the screen. When this warning is
displayed, the boat will be able to run unballasted for approximately
20 minutes before running out of fuel. Empty all ballast tanks and
immediately proceed to a fueling station before any further activity.
Continuing to operate the boat with low fuel levels could leave users
stranded oshore.
If an operator has inaccurately or mistakenly entered the fuel level,
there is a sensor in the fuel tank that will override the entered fuel
level when it senses low fuel. To avoid false readings, the sensor will
only override the fuel management system when it detects a low
fuel level for more than 30 seconds with the engine operating at
less than 900 RPM.
To disable the fuel management software and rely on traditional
fuel gauge readings:
• Push the Menu Hot Key on the HV700 screen.
• Tap User Settings.
• On the User Settings page select either ENABLE or DISABLE under
Fuel Management.
Disabling the fuel management software will allow the fuel gauge to
read fuel levels directly from the fuel sensor on the fuel tank. Should
operators wish to turn fuel management back on, the easiest way
to do so requires enabling fuel management on the User Settings
page, filling the boat with fuel and inputting FULL on the fuel entry
screen.
When low fuel warning is displayed immediately empty all ballast
tanks and proceed to the nearest fueling station.
