2017 OWNERS MANUAL / 246
Location
A rocker switch mounted to the throttle control panel.
Operation
In all instances, the lights operate by using two position switches,
one position for ON and the other for OFF.
TOWER DOME LIGHT
Models
Standard on ZFT7 towers, optional on ZFT4 towers.
Purpose
The tower dome light illuminates the cockpit of the boat for use in
low light situations or at night.
Location
The tower dome light is mounted to the underside of the header box
on the tower (directly below the tow point).
MasterCraft boats should not be operated after dark, even with
navigation lights on. The lights have limited range and luminosity.
The boat may not be seen by other boat operations. In emergency
situations or if an outing has not concluded prior to dark, use visual
and sound signals to slowly return to shore. Attempting to operate
at higher speeds may result in damage to the boat as the opera-
tor may not be able to see obstructions in the water or other craft.
This is not covered under warranty. Also, serious injury or death to
individuals may result.
ADDITIONAL SPECIAL NOTE: In the ProStar model, if the boat is not
equipped with tower lighting, the navigational lighting is valid for
INLAND RULES ONLY.
Troubleshooting
If lights do not operate, check the main circuit breaker panel to de-
termine if a circuit may have tripped. Reset the circuit; if it continues
to trip, take the boat to an authorized MasterCraft dealer.
If the circuit breaker has not tripped, the bulb may have burned out.
Although some lights are LED, which rarely burn out, it is possible.
Take the boat to an authorized MasterCraft dealer to have the bulb
replaced.
DOCKING LIGHTS
Models
Optional on all X Series, XT Series and XStar models.
Purpose
Optional docking lights provide a significant aid to navigation in dark
conditions. Docking lights are especially useful when pulling up to a
dock or into a boat slip after dark.
Location
Two sets of bright LED lights mounted to the bow rub rail.
Operation
A rocker switch mounted on the helm control panel turns the lights
on and o. Press up on the switch to turn the lights ON (a green LED
light will appear on the switch when the docking lights are on). Press
down on the rocker switch to turn the docking lights OFF.
Troubleshooting
If the lights do not operate, check the main circuit breaker panel to
determine if a circuit may have tripped. Although the docking lights
are LED lights which rarely burn out, it is possible. Take the boat to
an authorized MasterCraft dealer to have the bulb(s) replaced when
necessary.
TOWER LIGHTS
Models
Optional on all X and XT Series and XStar models equipped with
ZFT4 or ZFT7 towers,
Purpose
Tower lights may be white or blue LED lights. These lights add visual
appeal as well as providing additional light to the area aft of the
boat. This can assist operators in keeping an eye on wakeboarders
and skiers.
