2017 OWNERS MANUAL / 386
Step 7
Install the propeller nut and tighten it into place to 50-ft-lbs with a
torque wrench.
Step 8
Install a new cotter pin and bend the ends around the shaft to lock
the propeller on the shaft.
CHANGING PROPELLERS
Step 1
Ensure the engine is OFF and the engine safety starting switch is
disconnected.
Step 2
Remove and discard the cotter pin.
Step 3
Remove the propeller nut.
Step 4
Tap the center hub of the propeller with a rubber mallet to release
the propeller. Inspect the shaft and propeller splines for damage.
Step 5
Thoroughly clean and apply a light coat of waterproof marine multi-
purpose grease to the splined area of the shaft and propeller.
Step 6
Align the splines and carefully install the propeller onto the shaft.
DO NOT FORCE THE PROPELLER INTO PLACE. If necessary, gently
tap the propeller into place with a rubber mallet.
