2
TABLE OF CONTENTS
Specifications ................................................................................................. Page 2
Rules for Safe Operation ..............................................................................Page 3
Description ...................................................................................................... Page 11
Adjustments .................................................................................................... Page 15
Operation ......................................................................................................... Page 20
Maintenance...................................................................................................Page 34
Troubleshooting .............................................................................................. Page 39
Exploded View & Part List ............................................................................ Page 40
Warranty .......................................................................................................... Page 48
PRODUCT SPECIFICATIONS
Model 240-0024
Supply power 120V, 60Hz
Rated current 15A
No load speed 4000RPM
Saw blade 12”x/1” 60T
Miter angle 50° left to 55° right
Bevel angle 48° left to 48° right
CUTTING CAPACITIES
Type of cut Angle Setting Maximum cutting capacity
Miter Bevel Thickness Width
Cross Cut 0° 0° 3 3/4-in. 7 3/4-in
Miter cut 45° 0° 3 3/4-in. 5 1/2-in
Bevel cut at
45° Right
0° 45° 1 1/2-in. 7 1/2-in
Bevel cut at
45° Left
0° 45° 1 7/8-in. 7 1/2-in
Compound cut 45° 45° 1 1/2-in. 5 1/2-in
NOTE: All cutting specifications will vary by blade type used, actual lumber
size,and compound miter saw. All dimensions are approximate.
