COMPOUND BEVEL /MITER SETTINGS
Key Bevel
Setting
Miter
Setting
Type of cut
IL 33.9° Left 31.6°Right Inside corner - Left side
1. Position top of molding against fence.
2. Miter table set at RIGHT 31.6°
3. LEFT side is finished piece.
IR 33.9° Right 31.6°Left Inside corner - Right side
1. Position top of molding against fence.
2. Miter table set at LEFT 31.6°
3. Right side is finished piece
OL 33.9° Right 31.6°Left Outside corner - Left side
1. Position top of molding against fence.
2. Miter table set at LEFT 31.6°
3. LEFT side is finished piece
OR 33.9° Left 31.6°Right Outside corner - Right side
1. Position top of molding against fence.
2. Miter table set at RIGHT 31.6°
3. RIGHT side is finished piece.
