• Align the hole (gg) on each end of the side splash guard
(N) to the screw (hh) on each side of the blade guard and
press the holes (gg) on the splash guard through the
screws (hh).
Page 21
ASSEMBLY
CAUTION: It is not necessary to loosen or remove
the screws (F) on the blade guard to install the side splash
guard.
N
N
FIG. 11C
gg
hh
hh
