Page 27
OPERATION
• With your hands on the handles (EE), push the stand toward
the ground until the tile saw is in an open position with
the release lever (JJ) locking into place.
OPENING STAND (FIG. 18D-18E)
• Step on the release lever (JJ) and pull the handles (EE)
toward you at the same time.
• Once the stand is released from the release lever, ease
the stand toward the oor by pushing the handles toward
the oor.
JJ
FIG. 18D
JJ
FIG. 18E
JJ
JJ
EE
EE
EE
EE
