INST
ALLATION
20
4.8 COMMISSIONING AFTER INSTALLATION
W
hen your ChargeMaster is not new, you
have to take into account that former users
may have changed the settings. Reset the
ChargeMaster back to factory settings when
there is any doubt (see section 5.2).
4.8.1 General
The factory settings of the ChargeMaster are optimal for
most installations. With some applications however, it is
desirable to change these settings. Therefore several
adjustments can be made. See chapter 5.
NOTE:
The DIP-switches must be adjusted prior to
commissioning; all other settings can only be
made after commissioning.
CAUTION!
Check the polarity of all wiring before
commissioning: positive connected to positive
(red cables), negative connected to negative
(black cables).
If all wiring is OK, place the DC-fuse(s) of the DC-
distribution to connect the batteries to the Chargemaster.
WARNING
When placing this fuse, a spark can occur,
caused by the capacitors used in the
Chargemaster. This is particularly dangerous
in places with insufficient ventilation, due to
the gassing of the batteries an explosion can
occur. Avoid having flammable materials
close by.
Now the Chargemaster is ready for operation. After
switching on the AC power supply the Chargemaster will
initiate the charging process.
4.8.2 MasterBus (optional)
During first commissioning the Chargemaster will be
recognized by the MasterBus network automatically. The
remote control panel of the MasterBus network will
indicate that a new device was found.
Some settings can only be changed via the MasterBus
interface. See section 6.3 for an overview of all available
MasterBus settings. Refer to the user’s manual of the
remote control panel to change these settings.
4.9 DECOMMISSIONING
If it is necessary to put the Chargemaster out of operation,
follow the instructions in order of succession as described
below:
1 Switch the Chargemaster to stand-by (see section
3.2).
2 Remove the DC-fuse(s) of the DC-distribution and/or
disconnect the batteries.
3 Remove the AC-fuse(s) of the AC-input and/or
disconnect the AC-mains.
4 Open the connection compartment of the
Chargemaster.
5 Check with a suitable voltage meter whether the
inputs and the outputs of the Chargemaster are
voltage free.
6 Disconnect all the wiring.
Now the Chargemaster can be demounted in a safe way.
4.10 STORAGE AND TRANSPORTATION
When not installed, store the Chargemaster in the original
packing, in a dry and dust free environment.
Always use the original packing for transportation. Contact
your local Mastervolt Service Centre for further details if
you want to return the apparatus for repair.
4.11 RE-INSTALLATION
To reinstall the Chargemaster, follow the instructions as
described in this chapter (chapter 4).
