Mass Charger 24/50-2, 24/75, 24/75 (120V), 24/100, 3-24/100, 48/25, 48/50 – User and Installation Manual
17
Meaning
Factory setting
Adjustable range
General
Max. current
Maximum charge current, adjustable model
dependent.
(Max current)*
0 – I
max
*
Temp.
compensate
Charge voltage compensation for temperature
(V/°C).
-0.060/-0.120V/°C
-1.000 – 1.000V/°C
Bulk
Bulk voltage
Bulk voltage
28.50/57.00V
16.00-32.00/ 32.00-64.00V
Max. bulk time
Maximum bulk timer
480 min
0-600 min
Min bulk time
Minimum bulk timer
2 min
0-600 min
Start bulk time
Voltage at which to start the bulk timer.
27.60/55.20V
16.00-32.00/ 32.00-64.00V
Bulk ret. volt.
Return to Bulk voltage
25.60/51.20V
16.00-32.00/ 32.00-64.00V
Bulk ret. time
Adjustable Return to Bulk time after the Return to
Bulk voltage has been reached.
30 sec
0-255 sec
Absorption
Abs. voltage
Absorption voltage
28.50/ 57.00V
16.00-32.00/ 32.00-64.00V
Max absorption
Maximum absorption timer
240 min
0-600 min
Min absorp. time
Minimum absorption timer
15 min
0-180 min
Return amps
Return to Float current (in A)
6.0 %*I
max
0-25% * I
max
Float
Float voltage
Float voltage
26.50/53.00V
16.00-32.00/ 32.00-64.00V
Equalize voltage
Equalize voltage
31.00/62.00V
16.00-32.00/ 32.00-64.00V
Equalize time
Equalize time
360 min
0-600 min
Alarm set points
DC Alrm high on
Alarm DC High on
32.00/64.00V
16.00-32.00/ 32.00-64.00V
DC Alrm high off
Alarm DC High off
30.00/60.00V
16.00-32.00/ 32.00-64.00V
DC Alrm low on
Alarm DC low on
20.00/40.00V
16.00-32.00/ 32.00-64.00V
DC Alrm low off
Alarm DC low off
22.00/44.00V
16.00-32.00/ 32.00-64.00V
DC Alrm delay
Alarm delay time
30 sec
0-255 sec
Traction settings
Bulk voltage
Bulk voltage
29.20/58.40V
(read only)
Max bulk time
Maximum bulk time
360 min
(read only)
Min bulk time
Minimum bulk time
4 min
(read only)
Start bulk time
Start bulk time
27.60/55.20V
(read only)
Bulk ret. volt.
Bulk return voltage
25.60/51.20V
(read only)
Bulk return time
Bulk return time
30 sec
(read only)
Abs. voltage
Absorption voltage
28.90/57.80V
(read only)
Max absorp. time
Maximum absorption time
480 min
(read only)
Min absorp. time
Minimum absorption time
15 min
(read only)
Return amps
Return to Bulk current (in A)
6.0 %*I max
(read only)
Float voltage
Traction float voltage
26.50/53.00V
(read only)
NiCad settings
Bulk voltage
Bulk voltage
29.00/58.00V
(read only)
Max bulk time
Maximum bulk time
480 min
(read only)
Min bulk time
Minimum bulk time
2 min
(read only)
Start bulk time
Start bulk time
26.50/53.00V
(read only)
Bulk ret. volt.
Bulk return voltage
10.00/20.00/40.00V
(read only)
Bulk return time
Bulk return time
30 sec
(read only)
Abs. voltage
Absorption voltage
29.00/58.00V
(read only)
Max absorp. time
Maximum absorption time
480 min
(read only)
Min absorp. time
Minimum absorption time
15 min
(read only)
Return amps
Return to Bulk current (in A)
6.0 %*I max
(read only)
Float
NiCad float voltage
26.00/52.00V
(read only)
