Mass Charger 24/50-2, 24/75, 24/75 (120V), 24/100, 3-24/100, 48/25, 48/50 – User and Installation Manual
Meaning
Factory setting
Adjustable range
MLI (Li-ion) settings
Bulk voltage
Bulk voltage
28.50/57V
(read only)
Max bulk time
Maximum bulk time
480 min
(read only)
Min bulk time
Minimum bulk time
2 min
(read only)
Start bulk time
Start bulk time
26.50/53.00V
(read only)
Bulk ret. volt.
Bulk return voltage
26.30/52.60V
(read only)
Bulk return time
Bulk return time
240 sec
(read only)
Abs. voltage
Absorption voltage
28.50/57V
(read only)
Max absorp. time
Maximum absorption time
240 min
(read only)
Min absorp. time
Minimum absorption time
15 min
(read only)
Return amps
Return to Bulk current (in A)
6.0 %*I max
(read only)
Forced Float
LI-ion forced float voltage
27/54V
(read only)
* Depending on model
Events
Event x source
Event-based command.
Mass Charger event that should result in an action by
another device on the MasterBus network.
Disabled
See Event source list.
Event x target
Select a connected MasterBus device that should take
action due to a Mass Charger event.
Select…
Selectable targets are
system dependent.
Event x
command
Action to be taken by the target device.
Select…
See command list in
selected device manual
Event x data
Data is linked to the command.
On changes the status to On at the first signal.
Off changes the status to Off at the first signal.
Copy lets the status follow the input.
Copy Invert lets the status follow the opposite of the input
Toggle changes the status at the 1
st
signal and back at the
2
nd
signal. It is used in combination with a pulse switch.
Off
Off, On, Copy,
Copy Invert, Toggle.
Event x+1
The next event appears after enabling Event x.
Disabled
See Event x.
Mass Charger event source list (Mass Charger as event source)
Charging
Mass Charger state is On
Bulk
Charge stage is Bulk
Absorption
Charge stage is Absorption
Float
Charge stage is Float
Failure
Charger failure MasterBus alarm
CSI
Charger Status Interface MasterBus alarm to generate an audible alarm at charger failure
Equalize
Mass Charger is in Equalize mode
TC Error
Battery temperature sensor error
Fan
MasterBus signal for an external fan to start (at 50% load/50°C)
LED Bulk
LED Bulk illuminates
LED 20-40
LED 2 illuminates (see Figure 7)
LED Abs
LED Abs illuminates
LED 60-80
LED 4 illuminates (see Figure 7)
LED Float
LED Float illuminates
LED Failure
LED Failure illuminates
Mass Charger event target list (Mass Charger as event target)
Bulk
Command to start the Bulk stage of charge
Absorption
Command to start the Absorption stage of charge
Float
Command to start the Float stage of charge
On/ Standby
Command to switch on the Mass Charger
