Mastervolt MASS COMBI 24/2500-60

TECHNICAL DATA
42 May 2010 / Mass Combi 12/2500-100; 24/2500-60; 48/2500-35; 48/5000-70 / EN
10 TECHNICAL DATA
10.1 SPECIFICATIONS INVERTER
Model Mass Combi 12/2500-100 24/2500-60 48/2500-35 48/5000-70
Partnumber 36012505 36022505 36042505 36045005
DC input
Nominal battery voltage 12V 24V 48V 48V
Operating input voltage range 10.0 – 15.0V 19.0 – 31.0V 40.0 – 63V 40.0 – 63V
Absolute maximum voltage range
(No defects)
0.0 – 16.0V 0.0 – 32.0 V 0.0 – 65V 0.0 – 65V
Low battery switch off* (1-30 sec delay) 10.0V ±5% 19.0V ±5% 40V ±5% 40V ±5%
Low battery switch on* 11.0V ±5% 22.0V ±5% 44V ±5% 44V ±5%
High battery switch off* (No delay) 15.0V ±5% 31.0V ±5% 63V ±5% 63V ±5%
High battery switch on* 14.5V ±5% 29.5V ±5% 62V ±5% 62V ±5%
Max. ripple allowed on DC (No defects) 5 % RMS 5 % RMS 5 % RMS 5 % RMS
Nominal current at full load 200A 100A 50A 100A
Maximum peak current 400A 200A 100A 200A
Recommended Fuse 250A 125A 80A 160A
Wire size (up to 2m/6ft)
2x 70mm²/
AWG2/0
2x 50mm²/
AWG0
2x 35mm²/
AWG2
2x 50mm²/
AWG0
Recommended batteries 200~600Ah 100~300Ah 100~300Ah 200~600Ah
DC No load power consumption
Off mode 0mA 0mA 0mA 0mA
High power mode 230V / 0A out < 9W < 9W < 12W < 12W
Economic mode, 208V / 0A out < 8W < 8W < 10W < 10W
Idle mode, 5 pulses per 2½ sec < 0,5W < 0,5W < 0,5W < 0,5W
AC output
Nominal voltage (±5%) 230VAC (180– 250VAC)*
Wave form True sine wave, max 5% distortion, 2½% typical
Frequency 50Hz/60Hz +/– 0.05% (adjustable by DIP switch)
Maximum continuous output power (AC-out: 230V, resistive load)
- At 25°C / 77°F ambient temperature
2500VA (DC-in
≥11.0V)
2500VA (DC-in
≥22.0V)
2500VA
(DC-in ≥48V)
5000VA
(DC-in ≥48.0V)
- At 40°C / 104°F ambient temperature
2000VA (DC-in
≥11.0V)
2000VA (DC-in
≥22.0V)
2000VA
(DC-in ≥48.0V)
4000VA
(DC-in ≥48.0V)
Output power vs. ambient temperature
>25°C / 77°F derating –0.65% per °C / –1.15% per °F,
Shutdown at 80°C / 176°F internal temperature.
Surge capability (5 sec, resistive load) 4000W 4000W 4000W 7500W
Efficiency (100VA up to 2500VA) ≥90%
Load power factor range All power factors allowed
Protections
Over temperature, overload, short circuit, AC on output, high battery, low
battery.
* adjustable by means of MasterAdjust software
