SPECIFICATIONS
7 SPECIFICATIONS
Model: MasterBus – USB interface
Article number: 77030100
Delivery includes: Interface, USB connection cable, UTP patch cable, MasterBus terminating
device, user’s manual
Function of instrument: Communication interface between your PC and devices that are connected to
the MasterBus network
Manufacturer: Mastervolt Amsterdam the Netherlands
Powering capabilities: Yes, when the PC is switched on, it can power up to three non-powering devices
Power consumption: <9mA
Din rail mounting: Yes, Din rail 30 mm [1.2 inch]
Weight Approx. 80 gr [0.18 lbs]
Protection degree: IP 21
Dimensions: See drawing below
Figure 18:
Dimensions
in mm (inch)
and connectors
= MasterBus connector
USB = USB connector
USB
4,5 [0.18]
69 [2.7]4.0 [0.16]
33 [1.3]
33 [1.3]
6.0 [0.24]
78 [3.1]
32 [1.3]
4.0 [0.16]
Snijdersbergweg 93, 1105 AN Amsterdam, The Netherlands
Tel: + 31-20-3422100
Fax: + 31-20-6971006
Email: info@mastervolt.com
