SPARE PARTS LIST
40 Copyright © 2008 Mastervolt / December 2008 / WHISPER 15 ULTRA - Three Phase / US
50201814 O-ring
50209015
Seal
50201450 RAW WATER PUMP M12
Screw impeller
50209011 Impeller kit
Be a r ing
50209014
50209016 Circlip
50201811 Shaft
Male hose connector
50221031
Pump housing50201414
Seal
50209015
50209018 Screw cover
Cover type M12
50201401
Ga s ke t
50209012
Impeller K+ M
50209013
50221007
Male hose connector
O- ri n g
50209017
Be a r in g
50209014
50209019 Circlip
50209019 Circlip
Figure 30: Raw water pump complete Mastervolt type M12
