Mastervolt WHISPER 3,5 Installation Manual

July 2005 / MOBILE WHISPER 3,5 / EN 19
DIAGRAMS
& DRAWINGS
50201320 Dry exhaust kit 1”
no qtt article no description
61 1 ST 50220041 Exhaust hose 500mm SS male/female 1”
62 1 ST 50220042 Insul. blanket 35x60 exhaust hose 1 1/2
63 1 ST 50230520 Absorbtion muffler steel 1”
64 1 ST 50230521 Ressonance muffler steel 1”
65 1 ST 50230522 Insulation blanket R-muffler 1”
66 2 ST 50221401 Pipe nipple 1”x300mm galvanised
67 2 ST 50221421 Parallel male coupling 1” galvanised
68 2 ST 50221411 Straigt coupling f/f 1”galvanised
69 3 ST 50221661 U-clamp 42mm M10
70 3 ST 50221664 Bracket U-clamp 25cm M10/48mm passivated
71 6 ST 50211406 Washer SP M10
72 6 ST 50211447 Washer spring SP M10
73 6 ST 50211466 Nut hexogonal SP M10
75 1 ST 50221471 Elbow 90 degr m/f gavalvanised 1”
50201321 Combined radiator cooler kit W3,5 230VAC
no qtt article no description
2 2 ST 50221106 Straight reducer m/f1-1/2
3 1 ST 50221062 Mal nipple 1/2”
5 2 ST 50221003 Male hose connection 1/2x13
6 1 ST 50221007 Male hose connection 1/2x20
14 6 M 50220057 Cooling water hose warm water 13x21 mm
15 12 ST 50221521 Hose clamp stainless 12-20
16 16 ST 50221595 Hose support stainless 22x20 mm
17 1 ST 50230529 Bracket expansion tank for 50230531
17 1 ST 50230531 Expansion tank 20 mm
17 1 ST 50230532 Cap tank 050230531
20 2 M 50220011 Hose vacum SAE100R4 (3/4)” 19x31,5 mm
21 2 ST 50221502 Hose clamp stainless 19-29
31 1 ST 50201319 Combined radiator cooler W3,5 230V
32 2 ST 50221648 Adapter BSP 3/8
33 2 ST 50221107 Straight reducer m/f1-3/8
36 4 ST 50201121 Vibration mounting 30x25
37 4 ST 50211152 Bolt hexagonal ZP M8x16
38 4 ST 50211465 Nut hexegonal SP M8
39 8 ST 50211405 Washer SPM8
40 8 ST 50211445 Washer spring SP M8
41 6 M 50220001 Hose hydraulic 9,5x17,4 mm
42 1 ST 50221042 TEE fitting 1/2”
42 4 ST 50221655 BSP female swivel 3/8”-10
1 ST 50201300 Combined radiator cooler W3,5 12VDC
1 ST 50201305 Combined radiator cooler kit W3,5 12VDC
1 ST 50201310 Combined radiator cooler W3,5 24VDC
1 ST 50201312 Combined radiator cooler kit W3,5 24VDC
