DIAGRAMS & DRAWINGS
40 Copyright © 2009 Mastervolt / May 2009 / Whisper 7/9.5/15/20 Ultra for mobile applications / US
4.8 ELECTRICAL DIAGRAM RADIATOR FAN CONTROL 120VAC
Figure 44: Electrical diagram for standard fan control using 120V AC radiator fans
L1
L2
N
GND
AC LOAD
AIR FANS
GENERATOR
MAIN CIRCUIT
BREAKER
CIRCUIT BREAKER
6A
