Mastervolt Windmaster 500 User Manual

4
INSTALLATION
• Check whether the Windmaster 500 is mounted in a secure way.
6
•
A
fter starting up, the LED-indicator starts blinking yellow.
9
• If wind power is too low, the indicator will extinguish
• Connect the string cabling to the Windmaster 500. If wind power is sufficient, the
LED indicator will illuminate red.
7
–
+
• Connect mains cord to the
A
C-wiring. Then switch on the grid. If wind power is
sufficient, the LED-indicator starts blinking red: the Windmaster 500 is starting up.
This may last a few seconds
8
AC
