Mastervolt Windmaster 500 User Manual

3
INSTALLATION
• Mark the position of the two mounting spots A and B by using the
mounting bracket
2
A
B
• If necessary, drill mounting holes at spots A and B
A
B
3
• Fix the mounting bracket to the wall
4
A
B
• Read instructions on page 5 -8 prior to installation.
1
• Place the Windmaster 500 over the mounting bracket and then move it
downwards until it is locked by the mounting bracket
5
