USERS MANUAL WINDMASTER 500 ENGLISH
Choosing the location to install
Obey the following stipulations during installation:
• The Windmaster 500 is suited for indoor use
only.
• Ambient temperature: -20 ... 50°C; (power
derating above 40°C), Humidity: 0-90% non
condensing
• Choose a optimal location to avoid long DC and /
or AC wiring to minimize loses.
• Do not install the Windmaster 500 in
environments with heavy dust development or
humidity.
• If the Windmaster 500 is installed in the
immediate vicinity of living areas, take into
account that it produces a slight noise level when
operating.
• Mount the Windmaster 500 vertically on a solid,
non-resonating, wall.
• Mount the Windmaster 500 in such a way that
obstruction of the airflow through the ventilation
openings is prevented
• No objects must be located within a distance of
20 cm around the Windmaster 500.
• Multiple Windmaster 500 may be mounted next
to each other, not above each other. Minimum
spacing: 20 cm.
Things you need to install the Windmaster 500
Make sure you have all the parts you need to install
the Windmaster 500:
• The Windmaster 500
• Two screws (with plugs) to mount the
Windmaster 500. Maximum diameter: 4.5 mm.
Use mounting materials which are suitable to
carry the weight of the Windmaster 500.
• Tools to fix the screws / bolts with plugs into the
wall (screwdriver, drilling machine, a set of drills,
a pencil)
Directions for installation
The Windmaster 500 is equipped with a so called
“anti-islanding safety device”. It ensures immediate
switch off in case of grid failure. European countries
maintain different regulations with regard to anti-
islanding devices and the supply of energy back to
the utility grid in general.
In some countries one single Windmaster 500 may
be connected to an existing electricity branch circuit
which is fused with 16 Amp. In other countries
different restrictions apply. Please acquaint yourself
with the local regulations on this issue!
The Windmaster 500 is sold as a part of a system.
Your system vendor will provide the Windmaster
500 with the appropriate settings for the local
electrical grid. Never connect the Windmaster 500
to a utility grid which is not suitable for use with the
apparatus!
During installation you can check by means of the
LED-indicator whether the installation is done
properly. This check can only be carried out when
sufficient wind power is present.
Although the Windmaster 500 is protected against
wrong polarity, the positive (+) and negative (–) of
the wind turbine connections should not be
exchanged.
Install the product according to the instructions
stated on page 3 and 4.
Monitoring
The Windmaster 500 has a communication port that
can be connected to the COM-port (RS232) of a PC
or laptop. Use the provided “Mastervolt PC–link”
interface and cable to set up a connection.
Part number Description
130391030 PC-link Soladin/Windmaster,
incl. communication cable, 2m
NOTE: Communication is only possible
when sufficient wind power is present.
