USERS MANUAL WINDMASTER 500 ENGLISH
Operation
After installation the Windmaster 500 will switch on
automatically if wind power is sufficient. The
Windmaster 500 operates automatically: there is no
need for user adjustment or control. The
Windmaster 500 has no ON/OFF switch; If
necessary remove the fuse from the AC distribution
board to switch it off. Do not disconnect the
MultiContact plugs during operation of the
Windmaster 500! No specific maintenance is
required. If necessary, use a soft clean cloth to
clean the Windmaster 500. Never use any liquids,
acids and/or scourers.
Decommissioning
First remove the Fuse from the AC distribution
board before you disconnect the MultiContact plugs.
Now the Windmaster 500 can be demounted in a
safe way:
1. Push on the lower tab of the mounting bracket to
release the mounting lock.
2. Lift the Windmaster 500 upwards for
approximately 1 cm.
3. Move the Windmaster 500 straight from the wall
Warranty and Support
The inverter is supplied with a 2-year standard
product warranty. Other warranty agreements
between system vendor and Mastervolt may apply.
First line service and support is performed by the
system vendor. Defects caused by DC or AC over
voltage, out-of-specification short circuit current,
direct or induced lightning and surges as well as
cost of travel, installation and energy loss are
excluded from product warranty.
Liability
Mastervolt cannot be held liable for:
• Possible errors in this included manual and the
consequences of these.
• Use that is inconsistent with the purpose of the
product.
