Matco A400 User Manual

Manual Matco A400
3
2 Technical Data
2.1 Machine
Speed
3-12 revolutions per minute
Clearance height
Min. 3000mm
Environment
Clean, dry, non-aggressive
Operating temperature
0 to +45
o
C
2.2 Electric
Connection
1x230 VAC - 50 Hz, with protective earth
Installed power
1.1 kW
Insulation class
IP 54
2.3 Dimensions and weight
Weight
Approx. 500 kg
Dimensions (L x W x H)
2550x726x2772mm, turntable roller Ø1650mm
(Depending on model and version)
Product dimensions
1200x1000mm
Loaded height
Min. 500mm / max. 2500mm
Weight loaded pallet turntable
Min. 200kg / max. 2000kg
Film width to be processed
500mm
Film thickness
17 – 35 μ

Matco A400 Specifications

General

Brand	Matco
Model	A400
Category	Stretch Wrapping Systems
Language	English
