Manual Matco A400
4
3 Operation
3.1 Inserting film roll
1 - Place a film roll (direction of unwinding depends on the side of the cling).
2 - Apply film according to the illustration below.
CI = CLING INSIDE (adhesive side inside)
This is how the film has to be placed in the braking system if the adhesive side is on the inside of
the film, when unwinding it from the film roll.
CO = CLING OUTSIDE (adhesive side outside)
This is how the film has to be placed in the braking system if the adhesive side is on the outside of
the film, when unwinding it from the film roll.
