Manual Matco A400
10
3.4.3.1 Winding parameters
Adjustable parameters per programme: windings (left field up / right field down)
Windings at the underside: number of windings at the underside of the pallet.
Reinforcement windings: number of windings at a specific height. These windings allow
you to apply extra windings at a specific place.
Windings at the top: number of windings at the top of the pallet.
This button is the option button between single and spiral winding. (Active function is
green)
This button is the option button between winding with or without top layer. (Active
function is green)
Foil pincher off/on. (Active function is green)
This button is for saving the parameters. If it is operated, the changes are filed in the
right programme and you return to the ‘’Programme parameters’’ menu.
Representation of selected programme.
