Matco A400 User Manual

Manual Matco A400
18
NO.
QTY.
Part Number
Description
1
1
08137413
Base frame 1650 A series
2
1
08137769
Rear plate
3
1
08137490
Coverplate chain 1650
4
1
08137424
Turn disc A series 1650
5
8
08137734
Roller shaft
6
8
08137841
Roller
7
1
08138880
Motor Flange
8
2
08137947
Mounting Strip
9
1
000.263.600.860
Geared motor 0,55 kW 28 Rpm
10
1
08138206
Center shaft
11
1
08137835
Spacer Motor
12
1
08137581
Gear 10B-1 Z=22
13
1
08137836
Washer motor
14
1
000.216.200.320
Connecting link 5/8x3/8 (10B-1) ST
15
1
08140377
Gear 10B-1 Z=60
16
1
08137603
Sensorbracket for Gear
17
1
08138882
Roller Chain Substructure
18
16
000.201.017.030
Roller Bearing
19
1
000.201.100.010
Axial Ball Bearing
20
1
000.201.050.030
Ball Bearing
21
1
000.180.110.260
Locking Nut M48x1.5
22
1
000.180.110.270
Locking Shim M48
23
32
000.180.471.170
Circlip 17 x 1
24
1
000.180.444.080
Eye Bolt M10x70
25
5
000.187.991.235
Countersunk Screw M10x40
26
6
000.180.125.100
Washer M10
27
4
000.180.127.100
Spring washer M10
28
4
000.180.933.305
Hex Bolt Screw M10x40
29
1
000.180.934.100
Hex Nut M10
30
1
000.180.933.295
Hex Bolt Screw M10x30
31
4
000.180.912.210
Socket Head Schrew M8x16
32
4
000.180.125.080
Washer M8
33
4
000.180.127.080
Spring Ring M8
34
4
000.180.933.240
Hex Bolt Screw M8x25
35
2
000.180.933.160
Hex Bolt Screw M6x16
36
4
000.187.380.336
Button head screw with flange M6x20
37
2
000.187.380.320
Button head screw M6x10
38
4
000.248.200.006
Pipe clamp 302-6mm
39
4
000.180.125.060
Washer M6
40
4
000.180.933.155
Hex Bolt Screw M6x12

Matco A400 Specifications

General

Brand	Matco
Model	A400
Category	Stretch Wrapping Systems
Language	English
