Matco A400 User Manual

Manual Matco A400
26
NO.
QTY.
Part Number
Description
1
1
08140617
Foil unit frame
2
1
08141740
Frame sensor plate
3
1
08140383
Door
4
4
000.272.050.060
Roll Alluminium
5
1
08141763
Door sensor plate
6
1
000.172.205.140
Door Lever Latches
7
4
08140629
Nylon washer (M8)
8
1
000.272.050.080
Roll Alluminium
9
1
08137762
Pre-stretch roller
10
1
000.272.050.070
Roll Alluminium
11
1
08137753
Swing arm frame
12
1
08137794
Swing arm shaft
13
1
08137845
Swing arm sensor bracket
14
1
08137808
Fill-up tube Ï12 L=30
15
1
08129948
Adjustment Strip Spring
16
1
08129947
Fill-up Tube Ï10 L=10
17
1
08138060
Foil holder
18
1
08138061
Friction ring
19
1
08138411
Lamella plug
20
2
08137645
Tensioner bush 6mm
21
2
08137647
Tensioner plate
22
2
08137646
Tensioner bush 39mm
23
2
08138055
Tensioner shaft
24
2
08138056
Tensioner roller
25
1
08138065
Spacer Motor
26
1
08144019
Pulley T10 Z=27 B=16
27
1
08137637
Pulley T10 Z=16 B=16
28
1
08137638
Pulley T10 Z=12 B=16
29
1
000.223.025.304
Toothed belt T10 B=16 L=500
30
1
000.223.025.390
Toothed belt T10 B=16 L=600
31
1
000.263.600.880
Motor 0.25kW 18Nm 134rpm (Standard oil)
32
2
000.204.010.180
Collar Bearing Ï10
33
3
000.201.017.772
Flange bearing
34
2
000.201.012.060
Bearing Ï12xÏ24x6
35
1
000.196.216.200
Tension Spring 1 mm
36
2
000.248.102.010
Rubber Ï16xÏ6x20
37
1
08140475
Bracket
38
1
08140065
Protection Cover
39
2
08142075
Spacer wire bridge
40
1
08142067
Wire bridge
41
1
000.422.300.300
Earth Sticker
42
3
000.180.916.102
Set screw M5x6
